Energy Drink Beverage Solutions Beer Juice Carbonated Seaming Filling Machine

Basic Information
Place of Origin: CHINA
Brand Name: Jima
Model Number: JMM01
Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: wood carton
Delivery Time: 45-60 days
Supply Ability: 30 set per month
Contact Now
Detail Information
Name:: Cans Filling Machine Capacity:: 0-36000CPH
Processing Types:: No Gas Drink Or GAS Application:: Beverage Energy Drink Beer Juice Carbonated Drink
Supply Ability: 30 Set/Sets Per Month Lead Time:: 60 Working Days

Product Description

Beverage energy drink Beer juice carbonated drink canning seaming filling machine

Quick Details

Type:                      Filling Machine

Condition:               New

Application:             Beverage

Packaging Type:     Cans

Packaging Material:Metal

Automatic Grade:    Automatic

Driven Type:            Electric

Voltage:                   Customized

Power:                     5.2Kw

Place of Origin:        Shangahai, China (Mainland)

Brand Name:           Jima

Model Number:        BGF18-18-6

Dimension(L*W*H):  2450*1900*2300mm

Weight:                     2500kg

Certification:             CE, ISO2000

After-sales Service Provided: Engineers available to service machinery overseas

Name:                      Can filling machine

Degree of automation:Full auotmatic

Suitabl bottle shape:Can

Processing Types:    No gas Drink or GAS

Material:                   SUS304

PLC/ transducer/ touch screen:Siemens

Contactor/ air switch/supply:Schneider

Guarantee time:       2 years

Motor:                       Siemens/Chinese Brand

Capacity:                  0-36000CPH



Supply Ability:              30 Set/Sets per Month

Packaging & Delivery:  standard film packing or wood box packing.

Port :                            SHANGHAI

Lead Time:                   60 working days

Product Application

The juice can filling machine is like the name for filling juice into metal cans; For example juice, tea drinks etc which are made of concentrate juice. The final filling temperature will be around 85-90 degree centigrade; Once the thermal meter in juice filling machine is lower than the temperature, juice will be return to sterilizing machine again through return system.

Model
DGF12-4
Filling Head
12
Caaping Head
4
Capacity
5000-6000CPH
Filling precision
±1%
Power
5KW
Dimension
2100*1900*2100mm
Weight
3500KG



Main Features

- The machine is 3 in 1 filling machine, including bottle rinsing, juice filling and bottle capping; It is for tin can; For washing part, tin can will be sticked by magnet;
- Filling machine can be adjusted the height automatically basing on different height of bottles;
- For aluminum can, 2 in 1 filling machine will be needed, including filling and sealing; Washing tunnel will be extra machine;
- Metal cans must have the same diameter due to sealing part; It will not be shared by different diameters of cans;
- NOTE the touch screen will be apply “Pro-Face”, it can be remote control under internet condition; Once machine program down, we can modify in our factory;
- There is return system, including high position tank, return tank, vacuum pump and pump; For return juice to sterilizing machine;
- Except the juice, such filling machine can be used for filling water as well;
- The whole machine structure (all inside parts and outside structure) is totally new designed;
- Sanitary filling head system is of umbrella structure, high filling speed and perfect filling temperature control system and reflux tank system has the function of supplying the material automatically;
- More function can be added basing on requirement;
- High speed performance with less filling head;
- All the spare parts are made in one piece, which will be easy to change;
